| Pret: | 802 RON |
| Produse in stoc: | 1 |
| Garantie: | 1AN |
Specificatii tehnice
Nominal Diameter 320 mm (12 in)
Nominal Impedance 8 ohm
Minimum Impedance 6.2 ohm
Continuous Power
Handling800 W
Nominal Power Handling(AES)400 W
Sensitivity (1W/1m) 100 dB
Frequency Range 50 - 2000 Hz
Voice Coil Diameter 76 mm (3 in)
Winding Material Aluminium
Former Material Glass Fibre
Magnet Material Neodymium Inside Slug
Winding Depth 19 mm (0.75 in)
Magnetic Gap Depth 10 mm (0.4 in)
Flux Density 1.25 T
Surround Shape Double Roll
Cone Shape Exponential
Magnet Type Neodymium Inside Slug
Design
Spider Single
Pole Design Straight Pole
Recommended
Enclosure vol
42 dm3 (1.48 ft3)
Recommended tuning
freq.
65 Hz
Fs 50 Hz
Re 5.1 ohm
Qes 0.21
Qms 4.2
Qts 0.2
Vas 73 dm3 (2.5 ft3)
Sd 522 cm2 (80.9 in2)
EtaZero 4.3 %
Xmax +- 6.5 mm
Xvar +- 6.5 mm
Mms 53 g
Bl 20.1 Txm
Le 1 mH
Parameters
EBP 238 Hz
Overall Diameter 315 mm (12.4 in)
Bolt Circle Diameter 298 mm (11.7 in)
Baffle Cutout Diameter 283 mm (11.1 in)
Depth 141 mm (5.5 in)
Flange and Gasket
Thickness
14 mm (0.55 in)
Air volume occupied by
driver
2.5 dm3 (0.08 ft3)
Net Weight 3.9 kg (8.6 lb)
Shipping Weight 4.5 kg (9.9 lb)
Shipping Box 340x340x170 mm
(13.4x13.4x6.7 in)
Service kit RCK12NDL768
