Specificatii tehnice
Nominal Diameter 320 mm (12 in)
Nominal Impedance 8 ohm
Minimum Impedance 5.8 ohm
Continuous Power
Handling2000 W
Nominal Power Handling(AES)1000 W
Sensitivity (1W/1m) 93 dB
Frequency Range 40 - 1000 Hz
Voice Coil Diameter 100 mm (4 in)
Winding Material Copper
Former Material Glass Fibre
Magnet Material Neodymium Inside Slug
Winding Depth 26.5 mm (1.05 in)
Magnetic Gap Depth 11 mm (0.43 in)
Flux Density 1.15 T
Surround Shape Roll
Cone Shape Radial
Magnet Type Neodymium Inside Slug
Design
Spider Double Silicone
Pole Design T-Pole
Recommended
Enclosure vol
40 dm3 (1.41 ft3)
Recommended tuningfreq.40 Hz
Fs 39 Hz
Re 5.1 ohm
Qes 0.35
Qms 6.8
Qts 0.33
Vas 41 dm3 (1.45 ft3)
Sd 522 cm2 (80.9 in2)
EtaZero 0.7 %
Xmax +- 10.5 mm
Xvar +- 14 mm
Mms 152 g
Bl 23 Txm
Le 1.6 mH
Parameters
EBP 111 Hz
Overall Diameter 319 mm (12.5 in)
Bolt Circle Diameter 299 mm (11.8 in)
Baffle Cutout Diameter 281 mm (11.1 in)
Depth 137 mm (5.4 in)
Flange and Gasket
Thickness
13 mm (0.5 in)
Air volume occupied by
driver
2.7 dm3 (0.09 ft3)
Net Weight 8.2 kg (18 lb)
Shipping Weight 8.9 kg (19.6 lb)
Shipping Box 340x340x170 mm
(13.4x13.4x6.7 in)
Service kit
