Specificatii tehnice
Throat Diameter 50 mm (2 in)
Nominal Impedance 8 ohm
Minimum Impedance 8.3 ohm
Continuous Power Handling 220 W
Nominal Power Handling (AES) 110 W
Sensitivity (1W/1m) 108.5 dB
Frequency Range 0.5 - 18 kHz
Recommended Crossover 0.8 kHz
Voice Coil Diameter 75 mm (3 in)
Winding Material Aluminium
Inductance 0.14 mH
Diaphragm material Titanium
Flux Density 2.05 T
Magnet Material Neodymium Ring
Overall Diameter 131 mm (5.2 in)
Depth 85 mm (3.3 in)
Net Weight 2.7 kg (5.9 lb)
Shipping Weight (4
units)
11.4 kg (25.1 lb)
